Steel products can hide defects that no one can see — laminations inside a plate, porosity in a weld, a fine crack on a forged flange. NDT methods (non-destructive testing) find these defects without damaging the part. For metal suppliers, understanding NDT helps you read buyer specifications, plan inspections and price orders correctly.

Why NDT matters

Pipes, fittings, flanges and welds in pressure systems must be free from critical defects. Buyers and codes specify NDT to:

  • detect internal and surface flaws,
  • confirm weld quality,
  • meet code requirements (ASME, API, EN),
  • reduce the risk of failure in service.

NDT is performed by qualified technicians, usually certified to ASNT SNT-TC-1A or ISO 9712 at Level I, II or III.

1. Visual testing (VT)

The simplest and most widely used method. Trained inspectors examine surfaces, often with magnifiers, gauges and borescopes, for cracks, dents, pitting, laps, weld undercut and dimensional issues.

Best for: first-stage inspection of every product.

2. Dye penetrant testing (DPT or PT)

A coloured or fluorescent liquid is applied to a clean surface. It seeps into surface-breaking cracks. After the excess is removed, a developer draws the penetrant out, making cracks visible.

  • Finds: surface-breaking cracks, porosity, laps.
  • Works on: all non-porous metals, including stainless steel, aluminium and nickel alloys.
  • Limitations: only surface defects; requires very clean surfaces.

3. Magnetic particle inspection (MPI or MT)

The part is magnetised and fine iron particles (dry or in liquid, often fluorescent) are applied. Surface and near-surface cracks disturb the magnetic field and attract particles, showing an indication.

  • Finds: surface and slightly sub-surface cracks.
  • Works on: ferromagnetic materials only — carbon steel and low-alloy steel.
  • Does not work on: austenitic stainless steel, aluminium, copper.

4. Ultrasonic testing (UT)

High-frequency sound waves are sent into the material. Reflections from internal flaws or the back wall are displayed and analysed.

  • Finds: internal defects, laminations, lack of fusion in welds; also measures wall thickness.
  • Advantages: deep penetration, portable, no radiation, instant results.
  • Advanced forms: phased array UT (PAUT) and time-of-flight diffraction (TOFD) provide images and are increasingly used instead of radiography for welds.

UT is common for plate lamination checks, seamless pipe body testing, forgings and weld inspection.

5. Radiographic testing (RT)

X-rays or gamma rays (from sources such as Ir-192 or Co-60) pass through the part onto film or a digital detector. Differences in density show up as images of internal defects.

  • Finds: porosity, slag inclusions, incomplete penetration in welds.
  • Advantages: permanent record of results.
  • Limitations: radiation safety requirements, slower, harder on thick sections and on fillet or socket welds.

RT is widely specified for butt welds in piping. Our butt weld vs socket weld guide explains why butt welds are easier to radiograph.

6. Eddy current testing (ET)

An alternating current in a coil induces eddy currents in a conductive material. Defects change the current flow, which the instrument detects.

  • Finds: surface and near-surface defects in tubes and pipes; also used for sorting materials.
  • Advantages: very fast; ideal for automated testing of every tube at the mill.
  • Common use: heat exchanger and condenser tubes, welded stainless tubes and pipes; some standards allow ET as an alternative to hydro testing. See our hydrostatic test guide.

Choosing the right NDT method

Defect / product Typical method
Surface cracks on stainless DPT
Surface cracks on carbon steel MPI
Internal defects in plate or forgings UT
Butt weld quality RT or PAUT
Tube and thin-wall pipe Eddy current
Wall thickness on site UT thickness gauge

How buyers specify NDT

Enquiries may include lines such as:

  • "100% RT of longitudinal weld as per ASME Section V."
  • "UT for laminations on plates above 12 mm."
  • "DPT on all machined flange faces."
  • "ET on 100% tubes as per ASTM A1016/A450."

Each test adds cost and time. Price NDT as separate lines or confirm it is included. If a third party will witness tests, plan for that too — see third-party inspection for steel exports.

Documenting NDT results

Include NDT reports in your dispatch documents and reference them on your EN 10204 3.1 certificates. Each report should show the method, procedure, acceptance standard, equipment, technician name and qualification level, items tested and results. Software like MTCMitra keeps these references consistent on every certificate.

Frequently asked questions

Which NDT method is best?

There is no single best method. Surface methods (DPT, MPI) find cracks at the surface; volumetric methods (UT, RT) find internal defects. Specifications often combine them.

Can MPI be used on stainless steel?

Not on austenitic grades like 304 and 316, because they are non-magnetic. DPT is used instead.

Is UT replacing RT?

In many projects, phased array UT and TOFD are accepted alternatives to radiography because they avoid radiation hazards and give quick results.

What is ASNT Level II?

A Level II technician can set up equipment, perform tests and interpret results against acceptance criteria. Level III technicians develop procedures and oversee programmes.

Key takeaways

  • VT, DPT and MPI find surface defects; UT and RT find internal defects; ET suits tubes.
  • MPI works only on magnetic steels; use DPT on stainless.
  • Read NDT requirements carefully and price them in your quote.
  • Keep complete NDT reports with your certificates.
